SPL 2230 送料無料

SPL / 2230

SPL/DeEsser Mk2 (Model 2230) is an auto dynamic de-esser that reduces sibilance in mixes and vocal tracks without sacrificing the timbre or natural character of the voice.

■Auto dynamic de-esser
*This product requires an outlet that can supply AC115V 50/60Hz. Please note that it will not work properly with a regular household outlet (AC 100V) that does not boost the voltage.

SPL DeEsser Mk2 is a device that reduces sibilance in mixes and vocal tracks without sacrificing the timbre or natural character of the voice.

DeEsser automatically detects sibilant frequencies and creates a sound specific to that frequency without affecting adjacent frequencies. This S-Sound is phase inverted and mixed into the main signal to cancel out the sibilance. Even when the S-Reduction value is set high, the processing is so natural that the effect on voice characteristics and timbre is negligible.

2 channel de-esser
XLR/phone input/output
Female/male source selection
auto threshold

Analog inputs & outputs; XLR & TRS Jack (balanced)
Maximum input and output gain: 21 dBu
Input impedance: 21kΩ
Output impedance: 100Ω
Common mode rejection (1 kHz): > 80 dB
Frequency range (-3 dB): 10Hz -100kHz
THD + N (0 dBu, 10 Hz ? 22 kHz): -90 dB
Crosstalk (1kHz): -90dB
Noise (A-weighted): -97 dBu
Dynamic range: 118dB
Internal Linear Power Supply with Toroidal Transformer
Operating voltage for analog audio: 15V
Operating voltage for relays and LEDs: 12V
Mains Power Supply
Mains voltage (selectable): 230 V AC / 50; 115 V AC / 60 Hz
Fuse for 230V: T 200mA
Fuse for 115V: T 400mA
Power consumption: max. 15W
Dimensions & Weight
W x H x D (width x height x depth): 482 x 44 x 237 mm
Unit weight: 3.3kg
