- APOGEE/Symphony I/O MKII Dante Chassis with 8x8 Mic Pre Amps
APOGEE / Symphony I/O MKII Dante Chassis with 8x8 Mic Pre Amps
Variations
Apogee / Symphony I/O MKII is a multi-channel audio interface with the latest flagship AD/DA converter.
Multi-channel audio interface
Dante support
8x8 Analog I/O + 8 Mic Pre Amps + 8x8 AES/OP I/O (single slot populated)
Traditional high-quality sound and complete flexibility at a high budget-friendly price
The Symphony I/O Mk II 8x8 MP and Symphony I/O Mk II 16 MP Connect series are based on Apogee's proprietary AD/DA converters with high stability and performance, Advanced Step architecture. Apogee engineers have designed a simpler, more optimized analog circuitry using state-of-the-art components to provide a single modular board that can be used for a multitude of AD/DA converters, microphone preamplifiers, and other applications. This allows us to have a large number of AD/DA converters and mic preamps on a single modular board. The Symphony Connect series is a single Symphony I/O Mk II unit with up to 32 channels of mic preamps that offers unprecedented price advantages while maintaining Symphony's traditional quality. The Symphony Connect series is compatible with DanteR, ProToolsRHD, and ThunderboltR systems, implementing industry-leading sound quality and scalable, high-density I/O configurations. It is the ideal choice for various installations in broadcast, live sound, post-production, education, and even worship and congregation, as well as, of course, recording studios.
Symphony I/O Mk II Connect Series Key Features
Symphony's new analog inputs, with Advanced Stepped Gain mic preamps and world-leading A/D converters.
Microphone preamplifier section:
Noiseless gain adjustment up to 72 dB in 1 dB increments
Maximum input level of +26 dBu
Optimized performance through elimination of common-mode noise and improved EMI suppression
Supports impedance switching (2.4k/10k ohms) for passive microphone splits in live sound applications
Control of all mic preamps from Symphony I/O front panel, optional Apogee hardware remote, or Apogee control software
Simplified and optimized signal paths and carefully selected components deliver more channels with traditional flagship audio quality
Have flagship mic preamps in 8, 16, 24, or 32 channel configurations per unit
Supports Dante, Pro Tools HD, and Thunderbolt system connectivity
Inputs
Analog Inputs: 8 balanced inputs on 1x DSUB 25-pin connector
Eight mic preamps with up to 72dB of gain
Has Advanced Stepped Gain Architecture?
AES-EBU Inputs: 8 inputs on 1x DSUB 25-pin connector
(192k single wide)
Optical Inputs: ADAT, SMUX, S/PDIF compatible
ADAT: 8 channels 44.1-48 kHz
SMUX: 8 channels, 88.2-96 kHz
S/PDIF: 2 channels, up to 96 kHz
Coax input: 2 channels S/PDIF, up to 192 kHz
Outputs Analog Outputs: 8x balanced outputs on 1x DSUB 25-pin connector
AES-EBU outputs: 8x outputs on 1x DSUB 25-pin connector
(192k single-wide supported)
Optical outputs: ADAT, SMUX, S/PDIF compatible
ADAT: 8 channels 44.1-48 kHz
SMUX: 8 channels, 88.2-96 kHz
S/PDIF: 2 channels, up to 96 kHz
Coaxial output: 2 channels S/PDIF, up to 192 kHz
Hardware switch selects AES/OPTICAL digital input format
Connections Pro Tools HD Core card
Pro Tools Accel PCI card
Pro Tools HD Native PCI card
Pro Tools HD Native Thunderbolt card
Pro Tools HDX PCI card
Dante support
8x8 Analog I/O + 8 Mic Pre Amps + 8x8 AES/OP I/O (single slot populated)
Traditional high-quality sound and complete flexibility at a high budget-friendly price
The Symphony I/O Mk II 8x8 MP and Symphony I/O Mk II 16 MP Connect series are based on Apogee's proprietary AD/DA converters with high stability and performance, Advanced Step architecture. Apogee engineers have designed a simpler, more optimized analog circuitry using state-of-the-art components to provide a single modular board that can be used for a multitude of AD/DA converters, microphone preamplifiers, and other applications. This allows us to have a large number of AD/DA converters and mic preamps on a single modular board. The Symphony Connect series is a single Symphony I/O Mk II unit with up to 32 channels of mic preamps that offers unprecedented price advantages while maintaining Symphony's traditional quality. The Symphony Connect series is compatible with DanteR, ProToolsRHD, and ThunderboltR systems, implementing industry-leading sound quality and scalable, high-density I/O configurations. It is the ideal choice for various installations in broadcast, live sound, post-production, education, and even worship and congregation, as well as, of course, recording studios.
Symphony I/O Mk II Connect Series Key Features
Symphony's new analog inputs, with Advanced Stepped Gain mic preamps and world-leading A/D converters.
Microphone preamplifier section:
Noiseless gain adjustment up to 72 dB in 1 dB increments
Maximum input level of +26 dBu
Optimized performance through elimination of common-mode noise and improved EMI suppression
Supports impedance switching (2.4k/10k ohms) for passive microphone splits in live sound applications
Control of all mic preamps from Symphony I/O front panel, optional Apogee hardware remote, or Apogee control software
Simplified and optimized signal paths and carefully selected components deliver more channels with traditional flagship audio quality
Have flagship mic preamps in 8, 16, 24, or 32 channel configurations per unit
Supports Dante, Pro Tools HD, and Thunderbolt system connectivity
Inputs
Analog Inputs: 8 balanced inputs on 1x DSUB 25-pin connector
Eight mic preamps with up to 72dB of gain
Has Advanced Stepped Gain Architecture?
AES-EBU Inputs: 8 inputs on 1x DSUB 25-pin connector
(192k single wide)
Optical Inputs: ADAT, SMUX, S/PDIF compatible
ADAT: 8 channels 44.1-48 kHz
SMUX: 8 channels, 88.2-96 kHz
S/PDIF: 2 channels, up to 96 kHz
Coax input: 2 channels S/PDIF, up to 192 kHz
Outputs Analog Outputs: 8x balanced outputs on 1x DSUB 25-pin connector
AES-EBU outputs: 8x outputs on 1x DSUB 25-pin connector
(192k single-wide supported)
Optical outputs: ADAT, SMUX, S/PDIF compatible
ADAT: 8 channels 44.1-48 kHz
SMUX: 8 channels, 88.2-96 kHz
S/PDIF: 2 channels, up to 96 kHz
Coaxial output: 2 channels S/PDIF, up to 192 kHz
Hardware switch selects AES/OPTICAL digital input format
Connections Pro Tools HD Core card
Pro Tools Accel PCI card
Pro Tools HD Native PCI card
Pro Tools HD Native Thunderbolt card
Pro Tools HDX PCI card
