BOYA / BY-XM6-K1 Wireless microphone for smartphones

Wireless microphone for smartphones and SLR cameras. Has a headphone output for monitoring. The LCD model has a 3.5mm mini plug for easy device connection. Pairing is completed by simply turning the power on. Compact and lightweight. Captures targeted sound clearly and delivers high-quality sound. Easy-to-use wireless microphone system with simple operation. Comes with a charging case.

■Compact 2.4GHz wireless microphone

The BOYA BY-XM6-K1 is a 2.4GHz adaptive frequency hopping wireless microphone system with one transmitter, receiver, and charging case.

Advanced Technology for Stable Signal Transmission
The BY-XM6 K1 employs advanced adaptive frequency hopping (AFH) wireless signal transmission technology, which allows the microphone to automatically avoid disturbed hop frequency portions for stable signal transmission at ranges up to 100 meters (328 feet) without obstructions.

Professional Audio Recording and Distribution
High-quality capsule, with signal processing circuitry with a signal-to-noise of over 84dB and a distortion rate of less than 0.1%, provides high quality, transparent & low noise audio.

Super versatile & easy-to-use wireless microphone kit
The transmitter and receiver have vivid, easy-to-read OLED displays that allow precise adjustment of signal transmission. In addition, the transmitter has a built-in omnidirectional microphone, so the transmitter can be attached around the neck to pick up sound, or a lavalier microphone can be connected to the transmitter's MIC IN jack to pick up sound. In addition, the microphone kit incorporates a 3.5mm TRS-TRS audio cable and a 3.5mm TRS-TRRS audio cable. Therefore, it can be used with digital SLR cameras, mirrorless cameras, smartphones, and computers.

The BY-XM6 K1 incorporates a robust charging case that makes it easy to carry outdoors. The powerful built-in battery can fully charge the receiver and transmitter at the same time without cables. In addition, the charging case has a power indicator that makes it easy to check battery capacity and charging status.

- Ideal for YouTube video, live streaming, interviews, recording, etc.
- Works with DSLRs, mirrorless cameras, smartphones, and PCs
- 2.4GHz wireless
- High-fidelity and low-noise audio processing and system
- Has an easy-to-use, vibrant, informative OLED display
- Built-in omnidirectional and Lavalier microphones
The transmitter has Lavalier microphone
- Receiver incorporates headphone output jack for real-time monitoring
- Switchable between stereo and monaural outputs
- Built-in lithium-ion battery with 7 hours of operation in the transmitter and 6.5 hours in the receiver
The receiver provides 6.5 hours of use
- Can be used up to 100 meters in an unobstructed location
- Portable charging case incorporated

TX Transmitter
Transmission method: 2.4GHz digital frequency
Modulation method: GFSK
Operating range (unobstructed): Up to 328 feet (100m)
RF output power: <10mW
Polar Pattern: Omnidirectional
Frequency Response: 50Hz to 18KHz
Maximum SPL
Built-in microphone: 120 dB SPL
Lavalier Microphone: 110dB SPL
Sensitivity
Built-in microphone: -39dB
Lavalier Microphone: -39dB
SNR: > 84dB or better
Power Source
Built-in lithium-ion battery or USB-C DC 5V or charging contacts
Built-in battery life: approx. 7 hours
Antenna: PIFA antenna
Audio Input: 3.5mm TRS MIC/LINE IN jack or built-in microphone
Weight: Approx. 32g (1.13oz)
Dimensions: 62.1 x 31.6 x 16.5 mm
Operating environment temperature: -10°C to +50°C
Storage temperature: -20°C to +55°C

RX receiver
Transmission method: 2.4GHz digital frequency
Modulation method: GFSK
Operating range (unobstructed): Up to 328 feet (100m)
Audio Output Terminal
3.5mm headphone jack
3.5mm TRS output jack
Audio output level: -60dBV to -20dBV
Power source
Built-in lithium-ion battery or USB-C DC 5V or charging terminal
Built-in battery
Operating time: Approx. 6.5 hours
Antenna: PIFA antenna
Weight: Approx. 32g (1.13oz)
Dimensions: 62.1 x 31.6 x 16.5 mm
Operating environment temperature: -10°C to 50°C (-4°F to +4°F)
Storage temperature: -20°C to +55°C

Charging Case
Power requirements: USB-C DC 5V/1.5A
Power capacity: 3000mAh
Box charging time: 4.5 hours
Weight: 200g
Dimensions: 125 x 96.8 x 35.6mm
Operating Temperature: -10°C to 50°C
Storage Temperature: -20°C to +55°C
