TELEFUNKEN / TF47

Small diaphragm condenser microphone CC8 handmade in Vienna, Austria. Equipped with OCC7 capsule, which was inspired by the legendary CK1 capsule, it combines tradition and the latest technology such as high SPL support, transformerless circuit, and 2-step high-pass filter / pad.

The TELEFUNKEN TF47 is a newly designed condenser microphone based on the German sound inspired by the historic microphones U47 and M49. The deep low end and midrange add depth and presence to any source. Ideal for recording vocals, guitar on-mic, and drums.

Circuit Design
At the heart of the TF47 are brass K47-style capsules, 5840W tubes, and the custom-made BV8 transformer found on the U47.
With these components, the TF47 can deliver a warm yet punchy sound reminiscent of the U47.

feature
・ Midrange with a strong presence reminiscent of U47
・ Smooth and clear top end
・ Deep low end
・ Manual assembly in the United States
・ K47 style capsule and BV8 transformer

Use
・ Aggressive vocals such as R & B, rap, reggae, female soul singer
・ Upright base
・ Tam and kick drum
·trombone
·cello
·percussion

~ Specifications ~
■ Vacuum tube microphone
■ Directionality: Cardioid, bidirectional, omnidirectional
■ Tube Type: NOS 5840W
■ Sensitivity; 15mV / Pa
■ Voltage: 48V 48V (<3mA)
■ Output terminal: XLR 3 pin
■ Size: 200 mm L x 46 mm Dia
■ Mass: 695g
■ Accessories: M 903 power supply, M 803 microphone cable, ZC03 shell case, M 703 shock mount, M 782 stand mount, microphone sleeve
* 115V specification
