Blackmagic Design / Blackmagic Cloud Pod

Convert any USB-C disk to network storage. Equipped with a high-speed 10G Ethernet connection for extremely high-speed file access

■ Cloud pod

connection
■ 10G Ethernet port:
100/1000 / 10G BASE-T x1
■ USB-C port:
USB 3.0 x2 for external storage (up to 5Gb / s)
■ HDMI monitoring output: 1
■ Computer interface:
Ethernet (shared file access, configuration, software updates)
USB-C (configuration, software update)
File sharing protocol
■ Protocol: SMB
■ Computer connection: up to 50
Sync with the cloud
■ Compatible services: Dropbox

storage

■ Storage type:
Use your own drive
■ External storage:
USB disk
■ External storage format:
exFAT (Windows / Mac) or HFS + (Mac)

display
■ HDMI monitoring output format:
1080p50, 1080p59.94, 1080p60
■ Monitoring output display:
Device name, storage capacity and usage
Cloud sync status, user activity
Hardware status, storage map
Network data rate graph

■ Status indicator:
Horizontal light reads or writes
Lights red inside

Device control
■ External control:
USB-C or Ethernet (configuration and software updates)

software
■ Bundled software
Blackmagic Cloud Setup Utility
Blackmagic Proxy Generator Lite
Internal software upgrade with Blackmagic Cloud Setup via USB-C

■ Operating system
Mac 11.1 Big Sur,
Mac 12.0 Monterey or later
Windows 10, 11.

Power conditions
■ Power supply: External 12V DC 60W power supply x1.
■ Power input:
12V DC input (with 5.5mm lock ring) x1
■ Power consumption:
25W (without external USB disk)
■ Accessories
Universal power supply (fixed connector, international adapter)
Welcome wallet (with QR code for software download)
■ SIZE: 126.5 (W) x26 (H) x161.2 (D) mm
