ELECOM / VSP-HDP18BK

Distribute and output HDMI signals from computers, game consoles, etc. simultaneously to eight HDMI-equipped video devices such as displays and projectors, while maintaining high image quality and sound quality!

■Maximum display resolution: 4K60Hz (4096x2160)
■Main supported resolutions: 4K (4096x2160) 30Hz/60Hz, 4K (3840x2160) 30Hz/60Hz
2K (1920x1080) 60Hz, 1080i/720p/576p/576i/480p/480i
■HDMI standard: HDMI2.0b
■HDR: HDR10, Dolby Vision(R), HLG compatible (supported only in priority output mode)
■Data rate: 18Gbps
■Video frequency band: 600MHz
■Supported video output devices:
AV equipment with HDMI output terminal, home game consoles
Media streaming terminals, PCs, etc.
■Supported video display devices:
TVs, displays, projectors, etc. with HDMI input terminals
■Number of ports: Input: 1, Output: 8
■Connector shape:
Input: HDMI type A 19 pin (female) x 1, Output: HDMI type A 19 pin (female) x 8
Power supply: Micro-B connector x 1
■Permissible cable length: Within 5m on both input and output sides
■HDCP: HDCP1.4/2.2 compatible
■CEC: Only OUTPUT1 compatible
■HEC: Not compatible
■ARC: Not compatible
■Cascade: Up to 2 levels
■Compliant standards: VCCI Class B
■AC adapter rating: DC5V2A
■AC adapter input voltage: 100V-240V
■Body material: Metal
■Body size: Width approx. 320mm x Depth approx. 104mm x Height approx. 30mm
■Weight: Approx. 738g (body)
■Accessories: Dedicated AC adapter x 1, User's manual x 1
