ELATION / KLF048

A spotlight equipped with a 50W, 5600K cool white LED. Equipped with a Fresnel lens. Brightness and other settings can be adjusted using the buttons and knobs on the side of the unit.

■ Light Source - 150W Cool White LED Engine 5,600K, 97CRI - Average LED Life 50,000 hours (Note 1) ■ Photometric Data - Total Lumen Output 8,500+ - 9,269 LUX 861 FC @ 9.8 ft. (3m) (Min. Zoom) - 2,334 LUX 217 FC @ 9.8 ft. (3m) (Max. Zoom) - Zoom Range: 16°- 39° - Beam Angle: 16.1°- 38° - Field Angle: 39.1°- 53.9° ■ Effects - Manual zoom - Electronic dimming and strobe - Variable 16-bit dimming modes and curves ■ Color - 5,600K Cool White LED ■ Control/Connection - Manual and DMX controlled dimming and shutter - Rotary dial for dimming and zoom - 5 DMX channel modes (1/ 2/3/4/5) - 4-button control panel LCD menu display - RDM (Remote Device Management) - 3/5-pin DMX and IP65 locking power cable input/output - Wired digital communication network ■ Size/Weight - Length: 344mm - Width: 273mm - Height: 393mm - Weight: 8.4kg ■ Power - AC100V 50/60Hz - Maximum power consumption: 180W - Temperature range: 5°F- 113°F (-15°C- 45°C) - Power link: 9A ■ Accessories - Gel frame and rotating barn door - IP65 locking power cable - Barn door ■ Approvals/Ratings - CE | cETLus | IP30 Note 1: Under test lab conditions. May vary due to factors including but not limited to environmental conditions, power/voltage, usage patterns (repeated on/off), control and dimming.
