SENNHEISER / 508922

This is a 1-channel wireless receiver made by SENNHEISER. It is easy to set up.

■Overview XS Wireless 1 DUAL is a two-channel wireless system ideal for vocals and speech. Designed with ease of use in mind, this analog UHF system features a sleek dual-channel receiver with built-in antenna and the streamlined interface of Sennheiser's popular XS Wireless 1 series. - Easy for anyone to set up - License-free B-type, up to 7 units can be used simultaneously (limited to use when transmitter and receiver are more than 5m apart and transmitters are more than 20cm apart) - Frequency setting is auto-setup with scan function - Handheld transmitter with easy-to-use vertical switch - Runs for approximately 10 hours on two alkaline AA batteries - Receiver has a built-in antenna for easy setup ■EM-XSW 1 Modulation: Wideband FM Frequency range: 806.125 - 809.750 MHz Receiving frequency: Select from preset bank channels Receiving method: Antenna diversity Antenna input: Built-in antenna Squelch: Adjustable from 3dBμV to 28dBμV AF output level (peak deviation, 1kHz): 6.3 mm jack: +6 dBu, XLR -3M: +12 dBu Line / Mic level: 20 dB switchable AF output adjustment range: Adjustment range 45 dB (5 dB steps) Signal to noise ratio: - 103 dBA Power supply: 12 V DC / 300 mA Housing: ABS Dimensions: approx. 200 x 42 x 127 mm Weight: approx. 340 g
