Blackmagic Design / HyperDeck Studio HD Mini (HYPERD/ST/DAHM)

【国内正規品】H.264、ProRes、DNxHDファイルをSD/UHS-IIカードや外付けUSBディスクに、1080p60までのSDおよびHDフォーマットで収録できる小型デッキです。

Connection
■SDI video input: 1
■SDI video output: 1
■SDI rate: 270Mb, 1.5G, 3G
■HDMI video output: 1
■Screen: 2.2" LCD
■Timecode connections
■BNC input x 1, BNC output x 1
■Reference connection: BNC input x1, BNC output x1
■Reference connections: 1 BNC input, 1 BNC output, tri-level sync or black burst.
■SDI audio input
16 channels of embedded audio
■SDI audio output
16 channels of embedded audio.
■HDMI audio output
8 channels of embedded audio
■Remote control: 1 x RS-422 input
RS-422 input x 1
■Recorder configuration
Recorder configuration: User interface or via Blackmagic HyperDeck Ethernet Protocol
■Ethernet: 1Gb/s
Ethernet: 1Gb/s
■Computer Interface.
1 x USB Type C 3.0 (up to 5Gb/s) for external drive recording, webcam output, software configuration and updates

Formats
■SD video format
525i59.94 NTSC, 625i50 PAL
■HD video format: 720p50, 720p59.94 NTSC, 625i50 PAL
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080P23.98, 1080P24, 1080P25, 1080P29.97, 1080P30, 1080P50, 1080P59.94, 1080P60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
■2K DCI video format: 2Kp23.98 DCI
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI,
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI
■SDI standards: SMPTE 259M, SMPTE 259M, SMPTE 259M
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2084, SMPTE 2108-1
Supported SDI metadata: HD RP188, closed captioning
HD RP188, closed captioning CEA-708, HDR metadata supported by SDI
■Supported HDMI formats
Supported HDMI formats: 525i59.94 NTSC, 625i50 PAL,
720P50, 720P59.94, 720P60,
1080i50, 1080i59.94, 1080i60,
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60,
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30,
4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI
■Audio sampling rate
TV standard sample rate (48 kHz/24-bit)
■Video Sampling: 4:2:2 Y
4:2:2 YUV
■Color accuracy: 10-bit
■Color spaces: REC 601, REC 709, REC 2020.
REC 601, REC 709, REC 2020.
■HDR support.
Hybrid Log-Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084
■Multi-rate support.
Multi-rate support: SD and HD auto-detection
■Copy Protection
Capture from copyrighted HDMI sources is not possible. Please verify copyright ownership before capturing and distributing content.
■SIZE: 140(W)x44.2(H)x117(D)mm 820g
The power adapter is not included in this product. This product does not come with a power adapter. Please prepare a C13 type general-purpose power adapter separately when using this product.
