BOSE / ControlSpace EX-12AEC Conferencing Sound Processor

ControlSpace EX-12AEC is a conferencing sound processor from BOSE. It supports multiple AEC references and complements the EX-1280C in larger systems. Each AEC channel is equipped with non-linear processing and comfort noise. It supports Dante audio input and output. It can be connected to the EX-1280C or Dante-enabled microphones.

■Functions
・Channel AEC Expansion
Supports multiple AEC references to complement the EX-1280C in large systems
・Adaptive Noise Cancellation
Each AEC channel has non-linear processing and comfort noise functions to improve meeting clarity
・Dante Audio Network
Supports Dante audio input and output. Can be connected to the EX-1280C or Dante-compatible microphones
・Front Panel Interface
Equipped with a large OLED display and rotary encoder. Allows you to set network parameters and check channel operation.

■Applications
・Executive conference room
・Large conference room
・Distance lecture
・Multipurpose space
・Divided conference room
・Operation center

■Technology overview
・Signal processor: 32-bit fixed-point/floating-point DSP 456 MHz/ARM Cortex-A8 600 MHz
・Acoustic echo cancellation channels: 12
・PC configuration software: ControlSpace Designer software version 5.5 or later
・Maximum processing power: 3.6 GIPS/2.7 GFLOPS
・Audio Over IP: Dante, 16 x 16, primary/secondary, routable to AEC
