ESI / planet 22x

Dante audio interface

■ Features
・ Dante network audio interface with analog 2IN / 2OUT
・ 2 x XLR / TRS combo inputs
・ 2 x balanced XLR outputs
・ High-end 24bit / 96kHz AD converter with 118 dB dynamic range (Burr-Brown PCM4202)
・ High-end 24bit / 96kHz DA converter with 123 dB dynamic range (Burr-Brown PCM1795)
・ Professional low noise mic preamp with + 48V phantom power and adjustable gain for each channel
・ Volume adjustable headphone output
・ Step potentiometer that controls the master output level of the line output
・ 12V power adapter included
・ Power supply (PoE / Power over Ethernet) via network cable
・ ASIO 2.0, WDM (Windows 7, Windows 8.1 and Windows 10) compatible
・ Supports Core Audio (supports Mac OS X 10.7 or later)
・ Dante Virtual Soundcard for Mac / PC license included
・ Includes Bitwig Studio 8-Track
・ Size: Approximately 17.5cm x 12.0cm x 4.5cm
・ Weight: 540g

■ Product specifications
Hi-Z input selection switch (channel 1)
Microphone input selection switch (channel 1)
Peak LED (channel 1)
Input gain knob (channel 1)
Hi-Z input selection switch (channel 2)
Microphone input selection switch (channel 2)
Peak LED (channel 2)
Input gain knob (channel 2)
+ 48V phantom power LED
+ 48V phantom power switch
Master volume
Power LED
Headphone output terminal
On / Off switch
Headphone volume
