LYNX STUDIO TECHNOLOGY / HILO TB3 / BK

The LYNX STUDIO TECHNOLOGY / HILO TB3 is a digital interface that represents the pinnacle of analog conversion, with further improvements made to the Aurora (the first model), which incorporates Lynx's cutting-edge components and design technology.

■Digital Interface
■Black

2-in/6-out AD/DA Converter with Touchscreen [Thunderbolt 3 Connection] (Color: Black)

""Hilo was created for professionals who demand pristine audio quality.
Designed as a true all-in-one device, Hilo boasts best-in-class A/D/D/A conversion at its core, as well as a wealth of features like extensive metering and analysis tools, multiple inputs and outputs, and flexible routing and monitoring controls, all of which can be easily configured, saved, and recalled via the touchscreen. Unlike traditional stereo converters, Hilo features independent D/A converters and three stereo analog outputs with flexible routing. The main output, monitor output, and headphone output each have independent source combinations and level controls. ""

""Key Features
- Fully independent 2-in/6-out A/D/D/A conversion with digital expansion up to 32x32
- Unique custom-designed touchscreen interface
- Feature enhancements, improvements, and additions via firmware updates
- Future-proof design LSlot interface design - optional Thunderbolt*, USB, and Dante connectivity
- Real-time metering and analysis tools
- Flexible routing and monitor control
- High-quality headphone amplifier
- Field recording compatible - powered by a 9-18v DC battery pack in addition to standard AC power
- Two color options - black and silver

Specifications

- Line Input (L/R) Connector: XLR female connector
- Line Output (L/R) Connector: XLR male connector
- Monitor Output (L/R) Connector: 1/4"" TRS connector
- Headphone Output Connector: 1/4"" stereo headphone jack

- AES/EBU: Transformer-coupled XLR connector
- S/PDIF Coaxial: Transformer-coupled RCA jack
- S/PDIF Optical: Optical (TOSLINK) connector
- ADAT: 8 channels @ 48 kHz (optical connector selected)

Sample Rate:
Supports common sample rates up to 192 kHz, with high-precision processing by the SynchroLock sample clock generator

Clock Synchronization Source:
Internal
External Word Clock: 75ohm TTL signal via BNC connector, AES/EBU, or S/PDIF input

LCD Display: 480 x 272 LCD touchscreen

Computer with an Intel Core 2 @ 1.6kHz or equivalent AMD processor
2GB or more of free RAM
Windows 10 Fall Creators Update (64-bit edition)
macOS 10.12 Sierra, 10.13 High Sierra, or 10.14 Mojave
One available Thunderbolt 3 port (compatible with Thunderbolt 1/2 ports, requires an Apple adapter, sold separately)
Thunderbolt 3 cable (Sold separately)

*For details on the operating environment for each connection format, please refer to the distributor's website.
https://hookup.co.jp/products/lynx-studio-technology/hilo/lslot""
