Modor / NF-1

Modor's digital polyphonic synthesizer features unique features such as Modor's proprietary noisy oscillator and a Bowell filter that controls formants to create a human voice-like sound, something that is rare in hardware synths.

Key Specifications
Polyphony: 8 notes
Modes: Poly, Mono, Mono-Legato
Memory
448 patches, 14 banks [A to N], 32 patches
All factory presets can be overwritten
Connections
9V, 600mA AC adapter connection, center positive
MIDI IN/THRU/OUT: 3 x DIN 5-pin connections
Audio LR Output: 6.35 mm mono jack
Sustain Switch: 6.35 mm mono jack
Volume/Modulation Pedal: 6.35 mm stereo jack
USB Connector (MIDI only)
Front Panel Controls
42 rotary knobs
20 pushbuttons
Rotary encoder
Power switch/volume knob
Display
16-digit x 2-line green backlit LCD display
MIDI
All ""continuous"" sound parameters are controlled in real time via MIDI Sends and receives control changes
Modulation: pitch bend, velocity, aftertouch (channel & poly), mod wheel (CC#1), breath control (CC#2), CC#3 and expression pedal (CC#4)
Backup and patch swap via SysEx dump of patches, banks, and memories
Firmware upgrades via SysEx
MIDI MPE compatible
Rack mountable
Height: 6 rack units
Recessed rear connections for easy rack mounting
Rack mount ears included
