BAE / 1073MP DUAL Stereo Microphone Preamp

A microphone preamp that provides a fat, harmonically rich vintage sound, following in the footsteps of the Neve 1073. Dual channel version that supports a wide range of connections.

*This package does not include a dedicated power supply.

■Microphone preamp

The 1073MP is a microphone preamp version of the 1073 equalizer, well known for its distinctive Class A sound with a deep, rich low end, smooth highs, and thick mids. The Carnhill transformer input with two selectable impedances can be used with a variety of microphones, and it also has a line input for coloring the 2 mixes, and a DI input for all passive and active instruments. This microphone preamp is perfect for adding punch and character to your sound.

■Main Features

- Class A, transformer-coupled design in a 1U chassis
- 71dB GAIN supports low output ribbon microphones
- Input impedance switchable from 1200-300Ω
- Supports line level input
- High impedance DI for guitars, basses, etc.
- Equipped with polarity reversal switch
- Equipped with the same Carnhill St Ives transformer as the 1073 and 1084

■Specifications

Number of channels: 2
Frequency response: 10Hz-55kHz
Equipped with phantom power
Analog inputs: 2 x XLR (mic/line), 1 x 1/4"" (DI Hi-Z)
Analog outputs: 2 x XLR
Power requirements: Dedicated power supply required separately
Dimensions: 19W x 1.75L x 9D (1U rack size)
Weight: 4.54kg
