ATV / aD5(CH)

High-speed triggering analysis and low-latency sound generation process developed from scratch. Unique technology that sounds at the moment of impact brings out the drummer's groove. All materials are recorded in stereo high resolution and uncompressed. You can experience the original ""sound"", ""flavor"" and atmosphere of the instrument. You can also purchase additional tones on the manufacturer's website. You can always play with fresh sounds.

■Drum sound module
■Specifications
●Preset sounds
Kick x5
Snare drum x5
Tom set x4
Hi-hat x5
Ride cymbal x5
Crash cymbal x13
*Additional free/paid sounds can be downloaded from the ATV Sound Store.
●Preset drum kits
5 kits at time of shipment (additional kits can be added)
●Pad inputs
KICK
SNARE (3 Zones)
TOM 1
TOM 2
TOM 3
HI-HAT (2 Zones)
HI-HAT CONTROL
CRASH (2 Zones)
RIDE (3 Zones)
AUX 1 (2 Zones)
AUX 2 (2 Zones)
●Connection terminals
OUTPUT L/R: 2 x mono standard phone
PHONES: Stereo standard phone
AUDIO IN: Stereo mini phone
MULTI TRIGGER INPUT: Dedicated multi-connector
AUX TRIGGER INPUT 1/2: TRS standard phone
USB: 2.0 Type B connector (High Speed)
ATV LINK: RJ45 LAN connector
SD CARD: SD/SDHC card (up to 32GB)
DC IN: For use with the included AC adapter only.
●Power supply
DC 12 V
●Current consumption
600 mA
●External dimensions
197 (W) x 144 (D) x 73 (H) mm
●Weight
1.1 kg
●Accessories
AC adapter
Multi-trigger cable
Stand adapter
Quick start guide
