SENNHEISER / 509590

This is a plug-on transmitter compatible with the SENNHEISER evolution wireless 500 G4 series.

◆SKP 500 G4
Frequency range: 806.125-809.750MHz
Transmitting frequency: 30 frequencies, switching at 125kHz intervals
RF output: 10mW
Compander: Sennheiser HDX
Mute switch: AF/RF mute, disabled, switchable
Pilot tone squelch: switchable on/off
Input connector: XLR-3F
Input sensitivity adjustment range: adjustable in 48dB (3dB) steps
Signal-to-noise ratio (1mV, peak deviation): 115dBA or higher
48V phantom power supply: supported
Power supply: 2 1.5V AA alkaline batteries or BA2015 rechargeable battery
Operating time: usually 8 hours (48V off)
Dimensions: approx. 105 x 43 x 43mm
Weight (including batteries): 195g
