ELATION / KLF023

Variations

This spotlight features a Fresnel lens and is powered by a 350W, 3000K warm white LED. It features a motorized beam control, allowing you to adjust the beam angle from 12 degrees to 36 degrees. It supports DMX512 and RDM.

Light Source
- 350W Cool White LED Engine, 5600K, 97 CRI
- Average LED Lifespan: 50,000 hours (Note 1)

Photometric Data
- Maximum 14,000 lumen output
- 16,762 LUX 1,557 FC @ 9.8 ft (3 m) (Minimum Zoom)
- 1,462 LUX 136 FC @ 9.8 ft (3 m) (Maximum Zoom)
- Zoom Range: 11°-56°
- Beam Angle: 11°-56.2°
- Field Angle: 17.9°-77°

Effects
- Motorized Zoom
- Electronic Dimming and Strobe
- Variable 16-bit Dimming Modes and Curves

Color
- 5,600K Cool White LED

Control/Connectivity
- Manual and DMX-controlled dimming, shutter, and zoom
- Rotary dials for dimming and zoom
- Five DMX channel modes (2/3/3/6/7)
- 4-button control panel with LCD menu display
- RDM (Remote Device Management)
- 3/5-pin DMX and IP65 locking power input/output connections
- Wired digital communication network

■ Size/Weight
- Length: 445mm
- Width: 327.5mm
- Height: 456mm
- Weight: 12.7kg

■ Power Supply
- AC100V 50/60Hz
- Maximum Power Consumption: 430W
- Temperature Range: 5°F-113°F (-15°C-45°C)
- Power Link: 10A

■ Accessories
- Gel frame and rotating barndoor
- IP65 Locking Power Cable

■ Approvals/Ratings
- CE | cETLus | IP20

Note 1: Tested under laboratory conditions. Actual performance may vary based on factors including, but not limited to, environmental conditions, power/voltage, usage patterns (on/off cycling), control and dimming.
