ANTELOPE AUDIO / Discrete 8 with Premium FX collection
This interface is equipped with eight console-grade discrete mic preamps.
■ Specification
ANALOG
Analog Inputs
6 x Mic / Line Inputs
2 x Mic / Line / Hi-Z Inputs
Analog Outputs
1 x Monitor Out on TRS 1/4 Jacks, +20 dBu max
1 x ReAmp Out on TRS 1/4 Jacks
1 x Line Outs on DB25, +20 dBu max
2 x Stereo Headphone Outputs
Mic Preamp
EIN: -128 dBu (A-weighted)
Dynamic Range: -121 dB (A-weighted)
THD: -106 dB
Max input: +18 dBu
Gain Range: 65 dB
D / A Monitor Converter
Dynamic Range: 124 dB
THD + N: -101 dB
A / D Converter
Dynamic Range: 121 dB
THD + N: -112 dB
D / A Converters (Line Out)
Dynamic Range: 121dB
THD + N: -100dB
DIGITAL
Digital Inputs
2 x ADAT (up to 16CH)
1 x S / PDIF
Digital Outputs
2 x ADAT (up to 16CH)
1 x S / PDIF
USB 2.0 I / O
USB 2.0 Type B connector
Thunderbolt
Thunderbolt connector
CLOCKING
Word Clock Input
1 x Input @ 75 Ohms 3Vpp on BNC 32? 192kHz
Word Clock Outputs
3 x Outputs @ 75 Ohms 3Vpp on BNC 32? 192kHz
Clocking System
4th Generation Acoustically Focused Clocking
64-bit DDS
Sample Rates (kHz)
32, 44.1, 48, 88.2, 96, 176.4, 192
Other
Operating Temperature
0-50 ° C, 32-122 ° F
Weight (Approx)
3.0 kg / 6.61 lbs
Dimensions (Approx)
