Blackmagic Design / Teranex Mini - SDI to HDMI 12G

Converts from 12G-SDI to HDMI and supports all video formats including SD, HD, 6G, 12G-SDI.

■ 12G-SDI/HDMI converter
■ SDI video input: 12G-SDI x1 (SD/HD/2K/4K automatic switching)
■ SDI video output: 12G-SDI loop through x1
■ HDMI: HDMI 2.0 connector (A type terminal) x1 2160p60 compatible
■ Analog audio output: 2 channels of professional balanced analog audio (XLR terminal) Right XLR can be set for timecode output
■ AES/EBU audio output: 4-channel professional 110Ω balanced digital audio (XLR terminal) Right XLR can be set for timecode output
■ Embedded audio: 8 channels
■ Supported multi-rate: SD/HD/2K/4K automatic switching HDMI output is equipped with Instant Lock function
■ Update and configuration: USB or Ethernet
■ Supports reclocking
■ SDI input format
■ Supported SD formats: 525i59.94 NTSC, 625i50 PAL
■ Supported HD formats: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
■ Compatible 2K formats: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF,
■ Compatible Ultra HD formats: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
■ Supported 4K formats: 4K DCI 25p, 4K DCI 29.97p, 4K DCI 30p
■ HDMI output format
■ Supported SD formats: 525i59.94 NTSC, 625i50 PAL
■ Supported HD formats: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
■ Compatible 2K formats: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p
■ Compatible Ultra HD formats: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
■ Supported 4K formats: 4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p, 4K DCI 29.97p, 4K DCI 30p
■ HDMI color space: REC 601, REC 709
■ HDMI color accuracy: YUV 4:2:2, RGB 4:4:4 (HD/2K/4K)
■ 140x44x170mm 580g
*Power cable is sold separately.
