marantz Professional / MP-REC-007

The PMD561 is a professional-grade portable audio recorder packed with features and capable of recording audio to SD/SDHC cards. Its excellent stability and reliability make it ideal for a variety of audio recording situations.

■Handy Recorder

≪Specifications≫
■Audio System: Solid-State Recorder
■Media: Storage: SD or SDHC card; Recording Format: MP3 (320, 256, 192, 128, 64, 32 kbps), WAV (16, 24-bit)
■Sampling Rate: 44.1, 48, 96 kHz
■Channels: 2 (Stereo) or 1 (Mono)
■Frequency Response: 20 Hz - 24 kHz (±1 dB)
■S/N Ratio: 65 dB (Mic), 85 dB (Line), IEC-A-weighted
■THD (@0 VU): 0.08% (Mic), 0.02% (Line)
■Dynamic Range: 85 dB
■Input Connectors: Microphone Input (XLR) Sensitivity: 1.2 mVrms / 4.2 kΩ; Line Input (6.3 mm Standard Phone) Sensitivity: 0 dBu / 4.2KΩ, Line 2 Input Terminal (3.5mm mini jack) Sensitivity: 500mVrms / 20KΩ
■Output Terminals: Line Output Terminal (RCA Stereo) Standard Level: 2.0V / 10KΩ, Headphones Terminal (6.3mm Standard Stereo Phone) Standard Level: 16mW / 32Ω, Speaker (Built-in) Standard Level: 450mW / 8Ω
■Power Supply: Included power adapter (DC5V, 1.5A, center positive), four AA batteries (approximately 7 hours of operation), phantom power (+48V, max. 10mA), Power Consumption: 4.2W (recording/playback when using power adapter)
■Dimensions: Approx. 105(W) x 40(D) x 170mm (H)
■Weight: Approx. 353g (excluding batteries)

≪Features≫
■Professional-grade portable audio recorder capable of recording audio to SD/SDHC cards
■Compact, rugged design for excellent portability
■Built-in studio-grade stereo condenser microphone
■Selectable recording formats: stereo/mono, WAV, or MP3
■WAV supports sampling frequencies of 44.1, 48, and 96kHz
■Selectable 16-bit or 24-bit
■MP3 supports sampling rates of 32-320kbps (6 levels)
■SD card check function
■Keylock function restricts access to recorded data by setting a password
■Keylock function
■S/PDIF digital input terminal (coaxial)
■USB 2.0 terminal ( (High-speed data transfer supported)
■Large OLED display
■Built-in stereo speakers and headphone jack
■Pitch shift function with adjustable playback speed (-40% to +20%, variable in 5% increments)
■Retake recording function for easy re-recording of mistakes
■XLR mic/line stereo input jack
■Supports +48V phantom power
■Powered by included AC adapter or four AA batteries (sold separately)

~From the manufacturer's website~
Equipped with a wide range of features, including a high-quality built-in stereo condenser microphone, a phantom-powered external mic input, two line inputs (standard phone/mini stereo), a timestamp function, a retake recording function for easy re-recording of mistakes, a pitch shift function with adjustable playback speed, and a large, highly visible OLED display. It's ideal for recording live performances, vocals, and instruments, as well as LINE recording of DJ equipment and other devices, and it also features the PMD series' unique ""key lock function that restricts access to recorded data by setting a password,"" making it ideal for recording audio in a variety of situations that require mobility and reliability.
