ROLAND / TB-03　アナログモデリングシンセ

Reproduces the overwhelming presence of TB-303 with ACB technology with a thick synth bass sound!

■ Bass synthesizer
■ ACB faithfully reproduces the sound of TB-303.
■ Sequencer that reproduces the characteristic original behavior.
■ Equipped with effects that improve practicality.
■ A wide range of methods for linking with external devices.
■ Thoroughly focused exterior.
■ Inherit the characteristics of Roland Boutique.
● User memory
Pattern: 96 (4 groups (I, II, III, IV) x 3 sections (A, B, C) x 8 patterns)
Tracks: 7
● Waveform
2 (SAW, SQUARE)
● Controller
VOLUME knob
TUNING knob
CUT OFF FREQ knob
RESONANCE knob
ENV MOD knob
DECAY knob
ACCENT knob
OVERDRIVE knob
DELAY TIME knob
DELAY FEEDBACK knob
WAVE FORM switch
TRACK PATT. GROUP selector
MODE selector
TEMPO button
VALUE knob
PATTERN CLEAR button
RUN / STOP button
PITCH MODE button
FUNCTION button
Keyboard buttons (C, C #, D, D #, E, F, F #, G, G #, A, A #, B, C)
TIME MODE button
TRANSPOSE UP / DOWN buttons
ACCENT button
SLIDE button
BACK button
TAP button
● Effects
Overdrive (overdrive/distortion)
Delay (tape echo/digital delay/reverb)
● Indicator
7-segment 4-digit (LED)
PITCH MODE LED
NORMAL MODE LED
TIME MODE LED
● Connection terminal
TRIGGER IN terminal: Mono mini type
CV OUTPUT jack: Mono mini type
GATE OUTPUT terminal: Mono mini type
PHONES jack: Stereo mini type
OUTPUT terminal: Stereo mini type
MIX IN terminal: Stereo mini type
MIDI (IN, OUT) terminals
USB port: USB micro B type (audio and MIDI compatible)
● Power supply
Rechargeable nickel metal hydride battery (AA type) x 4
Alkaline battery (AA) x 4
USB bus power
● Current consumption
500mA (USB bus power)
● Battery life during continuous use
Rechargeable nickel metal hydride battery (AA): about 5 hours
*Varies depending on battery specifications, capacity, and usage.
● External dimensions
308 (width) x 130 (depth) x 52 (height) mm
Weight (including batteries, not including Boutique Dock)
940g
● Accessories
Boutique Dock: DK-01 (Silver)
instruction manual
DK-01 Instruction Manual
Safety precautions
Warranty
Roland user registration card
Alkaline battery (AA) x 4
