SPL / Volume 8

This is an 8-channel volume controller from SPL. It features a high-quality power supply and a design with large, easy-to-use knobs.

■ Volume Controller, 8-channel, High-end

~From the manufacturer's website~

Volume8 is an 8-channel volume controller. Many DA converters and sound cards require signal level changes at the converter output, resulting in lower bit depth in the monitoring signal and degraded sound quality. By using an active circuit design, it's possible to avoid the loss of linearity caused by impedance changes that occur in passive circuits.


■Specifications

■Input and Output

Electronically Balanced Instrument Amplifier

Input Socket: XLR

Output Socket: XLR

Normal Input Level IN1: +4dBu, IN2: +4dBu/-10dBu

Input Impedance: 22kOhm

Output Impedance: 600Ohm

Maximum Input Level: 20.0dBu

Volume Gain: ∞ to -4 dB

Volume Control Range: -80dB to +6.6dB

Headphone: -65dB to +14.9dB

Frequency Response: 10 Hz-100 kHz (-3 dB)

Common-Mode Rejection Ratio: >60dBu

THD + N: 0.002% (@1kHz, 0dBu input level, unity gain)

S/N Ratio: -102dB (A-weighted)

Crosstalk: >-80dBu (@1kHz)

Dynamic Range: 120dB

Power Supply: Voltage: 115V/230V, Power Consumption: 15W

Fuses (slow blow): 230V/50Hz: 315mA, 120V/60Hz: 630mA

Dimensions and Weight

External Dimensions (W×H×D): 215 x 80 x 220 mm

Weight: 1.9kg
