MUTEC / MC-2 - Signal Distributor

This distributor splits AES/EBU digital audio signals input from external devices into up to eight channels. Supports transmission methods with sampling rates from 32.0 kHz to 192.0 kHz, and performs automatic signal status detection and monitoring. Supports various AES3/11/3id/11id digital signals, and can also perform format conversion from AES3 to AES11.

■Input Terminals
- AES/EBU3, 11, XLR (female) x 1, Impedance 110Ω
- AES/EBU3id, 11id, BNC (female) x 1, Impedance 75Ω

■Output Terminals
- AES/EBU3, 11, XLR (male) x 6, Impedance 110Ω
- AES/EBU3id, 11id, BNC (female) x 2, Impedance 75Ω

■Power Supply
- AC 100V 50/60Hz 10W
