Blackmagic Design / Blackmagic URSA Cine 12K LF Body

Equipped with a new large format RGBW 36 x 24mm sensor, this digital camera has a large photosite that provides 16 stops of dynamic range.

■Digital film camera
■Effective sensor size
35.64mmx23.32mm (large format)
■Pixel pitch: 2.9μ
■Lens mount:
URSA Cine locking EF mount. Interchangeable with optional URSA Cine Mount PL
■Lens control:
Lens control for compatible EF lenses. Lens data from compatible PL lenses, controls for some PL lenses.
■Dynamic range: 16 stops

【connection】
■Total video output: 2
■SDI rate:
1.5G, 3G, 6G, 12G
■Analog audio input:
XLR analog (Mic/Line/AES audio switchable) x2. Supports phantom power.
■Analog audio output:
3.5mm headphone jack x1
■Reference input:
Tri-level sync/black burst/timecode
■Viewfinder:
Viewfinder USB-C (supports video, power supply, camera control data, locking connector) x1 Supports URSA Cine EVF and PYXIS Monitor.
■USB-C monitor output:
USB-C (side port for URSA Cine EVF, PYXIS Monitor, DisplayPort monitor) x2
■Accessories:
7-pin Lemo ""EXT"" (for power output, serial communication, run/stop) x1
3-pin Fischer ""RS"" (for power output, run/stop) x1
■Computer interface:
2x USB-C (side expansion port for camera accessories)
■Software updates use USB-C on the rear side
■Ethernet:
1x 10Gb/s RJ-45 connector (supports 10/100/1000/10G BASE-T for SMB file sharing, Web Media Management, Blackmagic Cloud upload, camera control, and distribution)

【audio】
■Microphone:
Built-in stereo microphone
■Built-in speaker: Mono speaker x1

【format】
■SD video format: Not supported
■HD video format:
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60.
■Ultra HD video format:
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60.
■SDI standard:
SMPTE 292M, SMPTE 424 Level B, SMPTE 2081-1, SMPTE 2082-1
■SDI audio sampling:
48kHz, 24-bit
■Included items:
Blackmagic URSA Cine 12K LF (EF lens mount)
Blackmagic Media Module CF
Blackmagic URSA Cine rubber cap for connectors
Blackmagic URSA Cine WiFi Antenna
Blackmagic EF Body Cap
DaVinci Resolve Studio (activation key)
Welcome wallet (with QR code for software download)

*The warranty period for this product is one year of the manufacturer's warranty.
