SPL DeEsser Mk2 送料無料

SPL / DeEsser Mk2

The SPL/DeEsser Mk2 (Model 2230) is an auto-dynamic de-esser that reduces sibilance in mixes and vocal tracks without compromising the natural character of the tone or voice.

■Automatic Dynamic De-esser

*This product requires an AC115V 50/60Hz outlet. Please note that it will not function correctly with a standard household outlet (AC 100V) without voltage boosting.

The SPL DeEsser Mk2 is a device that reduces sibilance in mixes and vocal tracks without compromising the natural character of the timbre or voice.

The DeEsser automatically detects the frequency of sibilance and creates a sound specifically for that frequency without affecting adjacent frequencies. This S-Sound is phase-inverted and mixed into the main signal to cancel out the sibilance. Even with high S-Reduction settings, the processing is so natural that the impact on vocal characteristics and timbre is negligible.

2-Channel De-esser

XLR/Phone Input/Output

Female/Male Source Selection

Auto-Threshold

Analog Inputs & Outputs: XLR & TRS Jack (balanced)

Maximum Input and Output Gain: 21 dBu

Input Impedance: 21 kΩ

Output Impedance: 100 Ω

Common Mode Rejection (1 kHz): > 80 dB

Frequency Range (-3 dB): 10 Hz - 100 kHz

THD + N (0 dBu, 10 Hz - 22 kHz): -90 dB

Crosstalk (1 kHz): -90 dB

Noise (A-weighted): -97 dBu

Dynamic Range: 118 dB

Internal Linear Power Supply with Toroidal Transformer

Operating Voltage for Analog Audio: 15 V

Operating Voltage for Relays and LEDs: 12 V

Mains Power Supply

Mains voltage (selectable): 230 V AC / 50; 115 V AC / 60 Hz

Fuse for 230V: T 200mA

Fuse for 115V: T 400mA

Power consumption: max. 15W

Dimensions & Weight

W x H x D (width x height x depth): 482 x 44 x 237 mm

Unit weight: 3.3kg
