ELECOM / PCA-DPSH3811BK

Display stand with 2 USB 3.0-Ax ports, 2 USB Type-C(TM) ports, 1 USB 3.0 Micro-Bx port, and AC adapter for charging, convenient for plugging and unplugging peripherals and charging!

■ Monitor stands Display stands
Supported sizes: Up to 27-inch displays
Load capacity: 10 kg
■Interface:
USB3.0 (Operates as USB2.0 compatible when connected to USB2.0 interface; operates as USB1.1 compatible when connected to USB1.1 interface)
■Connector shape:
PC side (upstream port): USB3.0 Micro-B (female) x1
USB device side (downstream port): USB3.0-A
USB3.0-A(female)x2 USB Type-C(TM)(female)x2
Supported OS: Windows(R)10, Windows(R)8.1, Windows(R)7, macOS Big Sur(11.0)
*Upgrading to the latest version of each OS and installing service packs may be required.
Maximum transfer rate: USB3.1 GEN1/5Gbps (theoretical), USB2.0/480Mbps (theoretical)
Number of upstreams (PC side) ports: 1
Number of downstream (peripheral device side) ports: 4
USB cable method: USB 3.0
USB cable length: approx. 100 cm (excluding connector)
Power supply method: Self-power (12V 1.5A) / bus power (5V 0.9A)
■Supply current: USB3.0 connection self-powered: 4 ports within 3,000mA total (less than 900mA for each port), bus-powered: 4 ports within 720mA total (less than 180mA for each port)
DC cable length (with included AC adapter): Approx. 150 cm (excluding connector)
Color: Black
■SIZE:
Display stand main unit: Approx. 380(W)x x40mm(H, when legs folded)/106mm(H, when legs stand up)x2308(D)
Weight: Product body: Approx. 1.026kg
Operating environment: 5 to 40°C (41 to 104°F), 30 to 80% humidity (no condensation)
Accessories: Dedicated AC adapter, USB-A-USB Micro-B cable, cable holder
