Blackmagic Design / HyperDeck Studio HD Pro(HYPERD/ST/DFHP)

【国内正規品】　Plusモデルの全機能に加え、SSDスロットおよびSDカードスロットをそれぞれ2つ搭載!

■ 12G-SDI loop output compatible recorder

Connection
■ SDI video input: 1
■ SDI video output: 2
■ SDI monitoring output: 1
■ SDI rate: 270Mb, 1.5G, 3G, 6G.
■ HDMI 2.0 video input: 1
■ HDMI 2.0 video output: 1
■ Built-in speaker: Mono
■ Audio output:
6.35mm headphone jack x1
■ Screen:
2.2 inch LCD
■ Timecode connection:
XLR input x1, XLR output x1
■ Reference connection:
BNC input x1, BNC output x1, ternary sink or black burst
■ SDI audio input:
16ch embedded audio
■ SDI audio output:
16ch embedded audio
■ HDMI audio input:
8ch embedded audio
■ HDMI audio output:
8ch embedded audio
■ Remote control:
RS-422 input x1, RS-422 output x1
■ Recorder configuration:
Via user interface or Blackmagic HyperDeck Ethernet Protocol
■ Ethernet: 1Gb/s
■ Computer interface:
USB Type C 3.0 x1 (up to 5Gb/s) for external drive recording, webcam output, software settings and updates

Format
■ SD video format:
525i59.94 NTSC, 625i50 PAL
■ HD video format:
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
■ 2K DCI Video Format:
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI,
2Kp29.97 DCI, 2Kp30 DCI
Ultra HD video format:
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
■ 4K DCI video format:
4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI
■ SDI standard:
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M,
SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2084, SMPTE 2108-1
■ Supported SDI metadata:
HD RP188, closed caption CEA-708. HDR metadata supported by SDI
■ Supported HDMI formats:
525i59.94 NTSC, 625i50 PAL,
720p50, 720p59.94, 720p60,
1080i50, 1080i59.94, 1080i60,
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60,
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI,
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30,
4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI
■ Audio sampling:
TV standard sample rate (48 kHz/24-bit)
■ Video sampling:
4:2:2 YUV
■ Color accuracy: 10-bit
■ Color space:
REC 601, REC 709, REC 2020. 33-point 3D LUT can be applied to SDI monitor output
■ HDR support:
Hybrid Log-Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084
■ Supported multi-rate:
SD, HD, 6G-SDI automatic detection
■ Copy protection:
Copyright-protected HDMI sources cannot be captured.
Please check copyright ownership before capturing and streaming content.
■ SIZE: 140 (W) x44 (H) x175.5 (D) 755g
