Blackmagic Design / Teranex AV

The teranex algorithm supports renowned Teranex image quality, consumer HiFi, XLR audio, HDMI input/loop/output and more!

■ Standard converter
■ SDI video input: BNC 1 system (IN A) -10-bit SD, HD, 2K, 3G HD (Level A and B), 6G / 12G UHD switchable
■ BNC 1 System (IN B)-Switchable between 10-bit SD, HD, 2K, 3G HD (Level A and B), 6G / 12G UHD 4: 2: 2 2nd input for 3G / 6G UHD Can be used as a dual link input
■ SDI video input loop: 1 BNC (IN A loop)-Reclockable 10-bit SD, HD, 2K, 3G HD, 6G and 12G UHD switchable
■ BNC 1 line (IN B loop)-Reclockable 10-bit SD, HD, 2K, 3G HD, 6G and 12G UHD switchable
■ SDI video output: BNC 1 line (OUT A)-10-bit SD, HD, 2K, 3G HD (Level A and B), 6G/12G UHD switchable, BNC 1 line (OUT B)-10-bit Switchable between SD, HD, 2K, 3G HD (Level A and B) and 6G/12G UHD 4:2:2 Can be used as duplicate output for 3G/6G UHD or dual link output
■ Quad SDI video output: 4 BNCs (channels A, B, C, D)-10-bit 3G-SDI quad link output when the processor output video format is Ultra HD. Other output formats have 4 connectors. Supports additional duplicate SDI output.
■ HDMI input: HDMI 2.0 type A connector 1 system
■ HDMI loop output: 1 HDMI 2.0 type A connector
■ HDMI output: 1 HDMI 2.0 type A connector
■ SDI audio input: SD, HD, 3G HD, 2K, Ultra HD compatible 16 channels
■ SDI audio output: 16 channels for SD, HD, 3G HD, 2K, Ultra HD
■ HDMI audio input: SD, HD, 3G HD, 2K, Ultra HD compatible 8 channels
■ HDMI audio output: SD, HD, 3G HD, 2K, 8 channels compatible with Ultra HD
■ Optical fiber connection (option): 1 SMPTE optical fiber SFP socket
■ Optical fiber video input: 10-bit 1 line (SD/HD/3G HD/2K/Ultra HD automatic switching)
■ Optical fiber video output: 10-bit 1 line (SD/HD/3G HD/2K/Ultra HD automatic switching)
■ Optical fiber audio input: SD, HD, 3G HD, 2K, Ultra HD compatible 16 channels
■ Optical fiber audio output: SD, HD, 3G HD, 2K, Ultra HD compatible 16 channels
■ Analog audio input: XLR 2 systems-2 channels of professional balanced analog audio (XLR is shared with AES/EBU audio input)
■ RCA 2 systems-Stereo unbalanced analog audio (for consumer equipment)
■ 482mm x 44mm x 125 mm 2kg
*Power cable is sold separately.
