Blackmagic Design / OpenGear Converter - SDI to HDMI

SDI / HDMI Video Converter

■ SDI/HDMI video converter
■ SDI video input: Switchable between SD/HD/3G-SDI
■ SDI video output: SD/HD/3G-SDI input is automatically matched
■ HDMI: HDMI type A output
■ Corresponding multi-rate: SD/HD/Level B 3G-SDI input automatic detection
■ Update and configuration: USB
■ Supports reclocking
■ Compatible SD format: 525i59.94 NTSC, 625i50 PAL
■ Compatible HD formats: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
■ Compatible 2K formats: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K 25PsF
■ SDI standard: SMPTE292M, SMPTE259M, SMPTE296M, ITU-RBT.656, ITU-RBT.601
■ SDI video rate: SDI video interface can be switched between SD/HD
■ Automatic SDI switching: SD/HD/3G-SDI is automatically selected
■ 356mmx77mm 140g
