Blackmagic Design / OpenGear Converter - HDMI to SDI

HDMI equipment / SDI converter

■ HDMI device/SDI converter
■ SDI video output: SD/HD matching automatically
■ HDMI: HDMI A type
■ Supported multi-rate: SD/HD is automatically detected
■ Supports reclocking
■ Compatible SD format: 525i59.94 NTSC, 625i50 PAL
■ Compatible HD formats: 720p50, 720p59.94, 720p60, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080i50, 1080i59.94, 1080i60
■ Compatible 2K format: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p
■ SDI standard: SMPTE292M, SMPTE259M, SMPTE296M, ITU-RBT.656, ITU-RBT.601
■ SDI video rate: SDI video interface can be switched between SD/HD
■ Automatic SDI switching
■ SD/HD is automatically selected
■ Compatible HDMI formats: 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080i50, 1080i59.94, 1080i60
■ 356mmx77mm 140g
