Blackmagic Design / Teranex Mini - Quad SDI to 12G-SDI

Quad Link SDI/12G-SDI Converter

■ Quad link SDI/12G-SDI converter
■ SDI video input: 12G-SDI x4 (SD/HD/2K/4K automatic switching)
■ SDI video output: 12G-SDI output x1
■ Embedded audio: 16 channels
■ Supported multi-rate: SD/HD/2K/4K automatic switching
■ Compatible SD format: 525i59.94 NTSC, 625i50 PAL
■ Compatible HD formats: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF29.97, 1080PsF25, 1080i50, 1080i59 .94, 1080i60
■ Compatible 2K format: 2K DCI 23.98, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
■ SDI video rate: SDI video connection can be switched between SD and HD level A/level B 3G-SDI/6G-SDI/12G-SDI
■ 140mmx170mmx44mm 580G
*Power cable is sold separately.
