Blackmagic Design / Teranex Mini - Analog to SDI 12G

Converts analog video to 12G-SDI. Convert analog devices like Betacam SP and VHS to high quality SD, HD and Ultra HD SDI video up to 2160p60!

■ Analog/12G-SDI converter
■ Analog video input: Component SD/HD, NTSC, PAL, S video
■ SDI video output: User selectable from SD/HD/12G-SDI
■ Analog audio input: 2 channels of professional balanced analog audio (XLR terminal) Right XLR can be set for time code input
■ AES/EBU audio input: 4 channels of professional 110Ω balanced digital audio (XLR terminal) Right XLR can be set for timecode input
■ Compatible multi-rate: SDI output can be switched between HD (composite/S-video) and Ultra HD (component HD)
■ Update and configuration: USB or Ethernet
■ Supports reclocking
■ SDI video rate: SDI video interface can be switched between SD/HD
■ Compatible SDI format: 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 2160p25, 2160p29.97, 2160p50, 2160p59.94, 1080i50, 1080i59.94, 1080i60
■ Compatible analog formats: 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60
■ 140x44x170mm 640g
*Power cable is sold separately.
