PANASONIC/WS-2260A Wall-mounted Double-Sided Speaker

PANASONIC / WS-2260A Wall-mounted Double-Sided Speaker

PANASONICお問い合わせ窓口

The Panasonic WS-2260A is a wall-mounted, double-sided speaker that supports high-impedance connections.

■Wall-Mounted Double-Sided Speaker

■Rated Input

6 W

■Input Impedance

1.66 kΩ, 5 kΩ

■Frequency Response

150 Hz ? 15 kHz

■Output Sound Pressure Level

92 dB (at 1 W/1 m)

■Second Signal Sound Pressure

94.1 dB (2 W), 98.7 dB (6 W)

■Speaker Type

Two 12 cm cone speakers

■Suitable Wire: Single copper wire

φ0.8 mm ? 1.6 mm

■Operating Temperature Range

-20 ℃ to +50 ℃

■Dimensions

103 mm (width) × 180 mm (length) × 290 mm (height) × 214 mm (depth)

■Weight

Approx. 2 kg

■Finish

Wooden enclosure

PVC sheet lamination (approximate Munsell N8 color)

■Net

Jersey (approximate Munsell N7 color)
