JBL / Control 24CT Micro

Variations

Recessed ceiling speaker, 4.5", 100V / 70V, pair

■ Ceiling embedded speaker
■ Pair

■ Frequency range (-10dB): 85Hz to 25kHz
■ Coverage angle (500Hz-10kHz average): 150 ゜
■ Sensitivity (1W, 1m): 86dB SPL
■ Transformer tap
100V: 9W, 4W, 2W, 1W
70V: 9W, 4W, 2W, 1W, 0.5W
■ Driver configuration
LF: 4.5 inches (114mm)
HF: 0.5 inch (13mm)
■ Crossover frequency: 3.5kHz
■ Input terminal: Screw
■ Color: white
■ Dimensions (φ × H): 200 × 117mm
■ Aperture size: 172mm
■ Mountable plate thickness: 10-30mm
■ Mass: 2.0kg
Accessories: C-type support bracket x 2, support rail x 4, bracket fixing screw x 4, cable fixing bracket x 2, opening template x 2, painting shield x 2, Japanese manual
